Before you actually migrate your database you need to think about what changes to your application you may need to do.
Azure SQL Managed Instances do not utilise windows authentication – so your two methods of authenticating applications and users are:
SQL Authentication:This authentication method uses a username and password.
Azure Active Directory Authentication:This authentication method uses identities managed by Azure Active Directory and is supported for managed and integrated domains. Use Active Directory authentication (integrated security) whenever possible.
Azure Active Directory (AAD) logins are the Azure version of on-premises database logins that you are using in your on-premises SQL Server instances. AAD logins enables you to specify users and groups from your Azure Active Directory tenant as true instance-scoped principals, capable of performing any instance-level operation, including cross-database queries within the same Managed Instance.
Note: Azure AD logins and users are supported as a preview feature for Azure SQL Managed Instances.
A new syntax is introduced to create AAD logins, which utilises “FROM EXTERNAL PROVIDER” i.e.
CREATE LOGIN [firstname.lastname@example.org] FROM EXTERNAL PROVIDER
compare this to our normal method of creating a login for a windows domain account
CREATE LOGIN [MorphiT\Hamish] FROM WINDOWS;
One of the key things to understand with Azure SQL Managed Instances is that if you are
leveraging AAD for authentication then the SID for the server level login will not be
the same as on-premises. This will be a consideration when you are migrating your database and users from on-premises to Azure SQL Managed Instance.
Just like any database migration where SQL Authentication is used, you will need to handle the mismatch in SID between the database user and Instance Login.
This means that you may have to use ALTER USER to link the AAD login to the database user. Which in effect will link the database user to the server login.
You can also remove the user and re-add them in – however this is quite a destructive method and you will have no certainty that you will get the securables correct or as they were before you removed the user.
The biggest consideration is – will your application handle AAD – if not then you will have to use SQL Authentication.
If you decide to use SQL Authentication initially and then move to AAD then you will need to re-engineer your application to leverage AAD….
This blog post is one that I have had percolating in the background since around November 2018.
My good mate John Martin ( t ) was speaking at PASS Summit on Azure SQL Managed Instances and we had talked about use cases, some of the gotchas and things to consider when migrating your databases to it.
I have been discussing Managed Instances (MI) with more people recently and this blog post is basically a run down of what MI is and how you can migrate to it with some considerations.
Before we go into MI we should look at what the current offerings were in Azure before MI became available in 2018.
We already had Azure SQL Database (introduced in 2010) and also the ability to run up SQL Server on an Azure VM. Both of these offerings were attractive as:
Azure SQL Database:
Server Administration is handled by Microsoft
You could scale out as required
Backups were fully managed
(BTW you can configure a long-term backup retention policy
to automatically retain backups in Azure blob storage for up to 10 years.)
We don’t have SQL Server Agent
It’s running 24/7
Cross-database queries are not native
No control of files and filegroups
Can’t use native backups for restore
No Service Broker
Backups are fully managed (for control freaks like myself this can be an annoyance)
Note: Azure SQL Database comes in Singleton databases or Elastic Pools
SQL Server running an Azure VM:
Good old familiar SQL Server
SQL Server Agent jobs!!
We can power down the VM if we do not require SQL Server 24/7
We still have to administrate a server
The costs associated with hosting VMs in Azure
The management overhead of hosting VMs in Azure
Introducing Managed Instances:
HA is built in
Infrastructure is handled by Azure
Can backup/restore to Azure Blob Storage
Lift & shift migrations
SQL Server Agent
Cross Database Queries
Linked Server (I know, I know….)
But like everything there are some cons.
Commissioning the Managed Instance can take a fair while.
We can’t shut it down so cost can be prohibitive if you have scaled it wrong.
Azure SQL Database Managed Instance does not currently support long-term backup retention
Here is a good comparison of Managed Instance vs Azure SQL Database
Reference: “Azure Managed Instance your bridge to the cloud”, Joey D’Antoni, SQLSaturday Cambridge 2018
Requirements for Azure Managed Instances
Configuring network environment:
You need to configure the network environment where Managed instance will be created. You will need to create an Azure VNet and a subnet where the instance will be placed.
Although the VNet/subnet can be automatically configured when the instance is created, the only drawback is the fact that it will configure it with some default parameters that you cannot change later.
If you already have a VNet and subnet where you would like to deploy your Managed Instance, you would need to make sure that your VNet and subnet satisfy networking requirements.
Creating Managed Instance:
Once we have the network environment configured the Managed instaqnce can be created. The easiest method is to use the Azure portal, however you can use PowerShell, PowerShell with ARM template, or Azure CLI.
My recommendation is to script it out as that adheres to my philosophy of using Infrastructure as Code to do pretty much anything where possible.
Be careful though…
Storage is vital to the performance of your database:
You need to size your underlying disk with throughput in mind:
So if we want at least 5,000 IOPS per disk then we need to size at P30 or combine smaller disks to achieve the necessary IOPS.
Provisioned capacity and performance
When you provision a premium storage disk, unlike standard storage, you are guaranteed the capacity, IOPS, and throughput of that disk. For example, if you create a P50 disk, Azure provisions 4,095-GB storage capacity, 7,500 IOPS, and 250-MB/s throughput for that disk. Your application can use all or part of the capacity and performance.
Azure maps the disk size (rounded up) to the nearest premium storage disk option, as specified in the table above. For example, a disk size of 100 GB is classified as a P10 option. It can perform up to 500 IOPS, with up to 100-MB/s throughput. Similarly, a disk of size 400 GB is classified as a P20. It can perform up to 2,300 IOPS, with 150-MB/s throughput.
Connecting to Managed Instance:
Essentially – Managed Instance is a private service placed on a private IP inside your VNet, so you cannot connect via public IPs.
You can connect to your Managed Instance in a variety of ways:
Create an Azure VM with installed SSMS and other apps that can be used to access your Managed Instance in a subnet within the same VNet where your Managed Instance is placed. The VM cannot be in the same subnet with your Managed Instances.
Setup Point-to-site connection on your computer that will enable you to “join” your computer to the VNet where Managed Instance is placed and use Managed Instance as any other SQL Server in your network.
Connect your local network using express route or site-to-site connection.
Validating your database before migration:
It is vital that you check that there are no differences between your SQL Server and Managed Instance. You need to understand what features you are using and whether you need to update your existing instance in order to migrate.
A good method is to install the Data Migration Assistant which will analyse the database on your SQL Server and alert you to any issue that could block the migration.
You also need to consider your authentication methods for your users and applications:
Native restore functionality that enables you to create a backup of your database, upload it to an Azure blob storage and RESTORE database from the blob storage. This is probably the faster approach for migration, but requires some downtime because your database cannot be used until you restore it on Managed Instance. You can even roll your own log shipping to it to minimise the amount of downtime.
Data Migration Service is a service that can migrate your database with minimal downtime. It does require vNet connectivity for source, VPN or Express Route to Azure.
Transactional Replication – this also minimises the amount of down-time and you can use a push subscriber model for Managed Instance
You can migrate up to 100 database on a single Managed Instance.
There are some differences in T-SQL syntax and behaviour between Managed Instance and on-premises SQL Server.
So there you have it – Azure SQL Managed Instances are live – some might say that they are the future of SQL databases in Azure.
I personally think that like anything it has it’s place. For new cloud based apps that require a SQL database in Azure I’d probably still use Azure SQL Database but of course there is that good old saying:
In late December 2018 I had a discussion with Amanda Martin the PASS Community Manager around things that I would be doing in 2019. I thought I would share the questions we discussed, and my replies below.
What are your professional goals for 2019?
My professional goals for 2019 are based around what SQL Server 2019 will bring to the Data Platform. I am looking forward specifically to the changes around SQL Server on Linux – specifically the Red Hat Enterprise Linux based images.
See my blog post where I run up the Ubuntu images on CentOS:
I have clients who are heavily into containers and this has driven me to start promoting this within the community – to help others learn about what containerized SQL Server is all about.
Is there a technology you want to learn or master?
As mentioned above SQL Server 2019 is going to be a great release in terms of what it can offer people to extend their data platform.
This in itself will be a technology that I will be mastering in 2019 and I look forward to be able to back-fill that knowledge to our community.
A technology I am looking forward to learn and master in 2019 is Azure Kubernetes Service (AKS).
The reason for this is I have presented on how powerful the Azure platform can be. I am also educating my clients and community around containers so this is a great partnership of both technologies.
In 2018 an area that I have been working in a fair bit has been Availability Groups and the fact that SQL Server 2019 CTP 2.2 allows for running an AG on docker with Kubernetes is exciting.
Using containers as part of a DevOps deployment pipeline for databases and applications is an area that will grow and being at the forefront of that is a driver for me in 2019.
Do you have a skill you want to upgrade?
I speak on continuous improvement – around deploying quality value every time you release software.
A skill I want to “upgrade” is my speaking skills, I want to spend time honing my speaking craft. I want to continually improve how I deliver content to the community and industry.
Being able to deliver quality content that helps people learn is fundamental to why I get up in front of crowds and talk about how to #MakeStuffGo
In terms of technological skills I want to upgrade – I always want to be a better Data Professional and so this year will be spent reading blog posts, registering for some of the fantastic (and free!!) webinars that PASS run.
Our Data Platform is growing exponentially and so a fair chunk of my free time will be spent ensuring that the skills I have within it are relevant, current and transferable.
What are your PASS community goals for 2019?
My PASS community goals for 2019 are to be more involved. To extend my reach and influence within the community. I live in New Zealand which is quite a remote country – which is a good thing and sometimes a bad thing when it comes to travelling (anywhere).
I want to be able to reach the wider community and part of this will be where I do more webcasts as opposed to writing. Being able to run webinars is a great way to connect and share content with a fair wider and diverse audience.
Are you already involved with a PASS Local or Virtual Group? If so, do you want to get more involved in these speaking, organizing and coordination opportunities?
I am already a PASS Local User Group Leader in Christchurch, New Zealand. I run the SQL Server and Data Management User Group which has grown from 250 members to 745 members in 3 years under my leadership.
I have recently been involved in the “rebooted” DevOps Virtual Group with Rob Sewell (t | w) which has been a fantastic platform for us to get the DevOps message out to the world via the PASS VG platform. Rob is a very energetic guy and I think it’s gonna be brilliant working with a guy who is as bouncy as myself!!
It means that at least twice a month I am speaking, organizing and coordinating educational content to up-skill people – for free. That in itself is awesome and thanks PASS for all the support you give us UG/VG leaders.
Do you want to share more ideas and content with the PASS community through blogging or publishing video content?
I certainly do – 2018 has been a proving ground year for me. Over the past 3 years being involved with PASS I’ve grown my contributions within the community and the reason I’ve grown it is that it is rewarding to see the impact of what we all can do. 2019 I will be looking at how I can do more with web based sessions – so that a more diverse group of people can learn from both myself and others.
Collaboration is a key thing in how I work and also in my personal life and I am looking forward to seeing how I can work with others to increase our “touch points” within the industry to help people connect, learn and share.
I am also looking to collaborate with some people on writing a book to help people learn via another medium.
Do you want to get involved with or plan a SQLSaturday for your local PASS community?
I already organize a SQLSaturday – SQLSaturday South Island. This event has grown each year since I took it over in 2016 and it now boasts Australasia’s largest % of WIT speakers.
I want to further this and a goal for 2019 is to be a more inclusive and diverse community based event.
This is an exciting goal as I have never been one to stray away from goals or from encouraging people to be part of a community.
I am looking forward to collaborating with a whole range of people within both my local and extended network.
So there you have it – 4 days into the New Year and I’m excited about where 2019 will lead me – both from a technological, personal and community perspective.
This blog post describes how to add the tSQLt unit testing framework to a database running in a docker container. You may have already read my article on how easy it is to install against a ‘normal’ SQL Server instance – running on windows…
The main reason why I run SQL Server in a container is so that I can run up specific versions – all from a script and generally as part of an automated build within Continuous Integration processes.
The first thing we need to do is spin up our docker container which has our SQL Server instance:
Just to verify that it is running let’s run
We can see that the container has an ID of 789f58fbef3f and a name of sql1 .
I have also mapped the default port of 1433 to 59666
We can now connect to SQL Server on port 59666 and do some typical queries whenever we connect to an instance for the first time:
Note that in the screenshot above – the servername result is the name of our container.
Now we can create our database and SQL Authenticated users as normal.
Yes – you interpreted that sentence correctly – right now you cannot use windows authenticated users against SQL Server running in a docker container on Linux. There is a way to get around this that I will be blogging about in late January 2019.
We can add our database to Source Control as per normal and apply the latest changes in our branch. I use the popular Redgate tooling for Source Control(and DevOps) activities
This is the framework itself. Now before you run this you have to do the following to get it to run in a database running in a container:
In the script you need to change PERMISSION_SET = EXTERNAL_ACCESS to be PERMISSION_SET = SAFE
We now run the script and voila – we have tSQLt in our database and can now write or run all the unit tests we want.
So there you have it – you can add tSQLt very easily (just 2 changes to make) to a database running in a docker container.
As mentioned the reason why I am very interested in running tests against databases running on container is around testing – I can spin up the container, download a particular patch level of SQL Server 2017 and above, add my database from source control, apply any referential data from source control and apply tSQLt which allows me to run a plethora of unit tests.
All within seconds and all consistently across multiple environment levels (QA, Integration, Functional test etc).
This blog post describes how easy it is to install the tSQLt framework.
Don’t know much about tSQLt? If you are serious about dealing with data in SQL Server then you should be as serious about unit testing the changes you are making to your stored procedures, functions and the like.
In fact I wrote a blog post about unit testing here:
This blog post is about a situation where after windows patching the SQL Server service and SQL Server Agent services will not start automatically – but will manually.
At a client site they had recently patched the servers – things went swimmingly – except the SQL Server services would not start.
Manually starting the services by right clicking | choosing start worked….
It is SQL Server 2017 with CU12 applied.
We tried a few things:
Making the services Automatic (Delayed)
Increasing the service pipeline timeout from 30 seconds to 60 seconds
But nothing worked.
Looking at the event logs I (eventually) found this:
Event ID 7000:
The MSSQLSERVER service failed to start due to the following error: The account name is invalid or does not exist, or the password is invalid for the account name specified.
Which is bizarre – as the service account had been used for months – but after each reboot the services had to be manually started. GPO and other things had been blamed but no one could actually find out why.
Just for a laugh – I decided to “rename” the service account.
From svcSQL@<domain> to <domain>\svcSQL
Rebooted and it worked.
Just to make sure it wasn’t a false positive I left the SQL Server Agent service how it was – and it did not start.
As to why this is the case – I’m not sure. To date I had always set up my SQL Server services with <domain>\<service account> so I have never stumbled across this – until now.
But I don’t care too much – it means that the client can reboot their server and know SQL Server will come back…
